Single camera obtains the image of cavity inner wall Penetrate into the hole for shooting, and the depth can be measured is large With light source, through hole and blind hole can be measured Applicableto inner wall detection of deep cavity and inner
It is suitable for the inner wall inspection of deeper cavities and inner holes
Download
| Model |
Side view Angle° |
Effective F Number |
Wavelength Range (nm) |
Probe diameter mm |
Probe length mm |
Object Field of View Inside diameter×Depth(（mm×mm） 1/3* 4.80*3.20 |
||
| Min | Typical | Max | ||||||
| TCSBI-13-12 | 70 | 22 | 450~650 | 10 | 67.7 | 12.0x6.6 | 15.0×8.8 | 25.0×16.1 |
| TCSBI-13-20 | 70 | 14 | 450~650 | 18 | 260.0 | 25.0×14.6 | 100.0×69.6 | Infxinf |
