The coil adopts distributed winding, with a high slot fill factor and good heat dissipation effect.
The moving coil has no iron core, so there is no attraction between the moving coil and the stator magnetic track.
The coreless rotor has no cogging effect and runs smoothly.
Compared with iron core motors, the mover has a lighter mass, which can achieve high acceleration and has better dynamic performance.
Download
| FIC40 Series Technical Data | |||
| Specification | FIC40-P01-A00-N00 | ||
| Rated voltage | V | 24,48VDC | |
| Peak torque | N.m | 0.3 | |
| Continuous torque | N.m | 0.1 | |
| Maximum velocity | rps | 15 | |
| Continuous velocity | rps | 10 | |
| Rotation position | Encoder resolution | pulse/rev | 524288 |
| Engraved line number | Lines | 2048 | |
| Absolute accuracy | arc-sec | ±50 | |
| Repeatability accuracy | arc-sec | ±5 | |
| Zero point | pulse/rev | 1 | |
| Maximum power | KVA | 0.028 | |
| Rated power | KVA | 0.006 | |
| Torque constant | Nm/Arms | 0.06 | |
| Back EMF constant | Vp/(krpm) | 5.1 | |
| Terminal Resistance | Q | 3 | |
| Terminal Inductance | mH | 0.53 | |
| Continuous current | Arms | 1.66 | |
| Peak current | Arms | 5 | |
| Pole pairs | - | 4 | |
| Load | Rotor inertia | kg.cm2 | 0.16 |
| Axial load(forward) | N | 30 | |
| Axial load(inversion) | N | 20 | |
| radial load | Nm | 0.2 | |
| Mechanical accuracy | μm | 10 | |
| Weight | kg | 0.4 | |
