Double telecentric design
High resolution
Excellent telecentricity,Ultra low distortion
Extremely high lighting uniformity
Design for high-end inspection and precision measurement
Download
| Model | Mag.X | WD mm |
Detector Type |
image circle (mm） |
Effective F Number |
MTF3 lp/mm |
DOF |
TV Distortion % |
Telecentricity ° |
Mount |
Dimensions mm×mm |
FOV mm×mm |
| TCACP2-1-0138-253-X | 0.138 | 253 | 1" | 120 | 6.6 | 120 | 27.7 | ≤0.1 | ≤0.1 | C | Ф156×353.7 | 86.96×72.46 (1") |
| TCACP2-1-05-100-X | 0.5 | 100 | 1" | 33.2 | 7.2 | 125 | 2.3 | ≤0.1 | ≤0.1 | C | Ф52×151.5 | 24.00×20.00 (1") |
| TCACP23-2-022-99-X | 0.22 | 99 | 2/3" | 50 | 4.5 | 160 | 7.4 | ≤0.1 | ≤0.1 | C | Ф73×174.5 | 38.41×32.14 (2/3") |
| TCACP2-23-05-100-X | 0.5 | 100 | 2/3" | 22 | 6.8 | 140 | 2.2 | ≤0.1 | ≤0.1 | C | Ф40×151.3 | 16.90×14.14 (2/3") |
