DDR motors are torque motors that directly drive the load without any transmission components. DDR motors have a compact structure and high rigidity.
Strong. They generate high torque by using high-energy permanent magnets. At the same time, they are equipped with built-in optical encoders, which make the system have better positioning accuracy.
Higher bit precision and a more dynamic response. The use of high-rigidity crossed roller bearings enhances the mechanical characteristics of the system.
Download
| FOl112 Series Technical Data | ||||
| Specification | FOI112 -Z03 -A00-N00 | FOI112 -Z06-A00-NO0 | ||
| Rated voltage | V | 220 | 220 | |
| Peak torque | N.m | 9 | 18 | |
| Continuous torque | N.m | 3 | 6 | |
| Maximum velocity | rps | 5 | 4 | |
| Continuous velocity | rps | 4 | 3 | |
| Rotation position | Encoder resolution | pulse/rev | 1048576 | 1048576 |
| Engraved line number | Lines | 4096 | 4096 | |
| Absolute accuracy | arc-sec | ±25 | ±25 | |
| Repeatability accuracy | arc-sec | ±2.5 | ±2.5 | |
| Zero point | pulse/rev | 1 | 1 | |
| Maximum power | KVA | 0.28 | 0.45 | |
| Rated power | KVA | 0.075 | 0.11 | |
| Torque constant | Nm/Arms | 2.14 | 4.28 | |
| Back EMF constant | Vp/(krpm) | 183 | 366 | |
| Terminal Resistance | Q | 4.3 | 7.6 | |
| Terminal Inductance | mH | 5.7 | 10.7 | |
| Continuous current | Arms | 1.4 | 1.4 | |
| Peak current | Arms | 4.5 | 4.5 | |
| Pole pairs · |
11 | 11 | ||
| Load | Rotor inertia | kg.cm2 | 27.5 | 51 |
| Axial load(forward) | N | 1000 | 1000 | |
| Axialload(inversion) | N | 800 | 800 | |
| radial load | Nm | 30 | 30 | |
| Mechanical accuracy | μm | 5 | 5 | |
| Weight | kg | 2.8 | 5.6 | |
