Use a smaller number of flat mirrors while shortening the length of the lens as much as possible
The mechanical specifications of the product are more compact than those of its competitors, saving installation space.
Download
| Model | Mag. (x) | WD (mm) | Detector Type | Effective F Number | MTF30 (lp/mm) | DOF (mm) | (%) | TV Distortion Telecentricity Mount (%) |
Mount
|
Dimensions (mmXmm) | FOV 1/2.5" (mmXmm) |
| TCAFR125-0072-258 | 0.072 | 258 | 1/2.5" | 4.1 | 190 | 63.3 | ≤0.1 | ≤0.1 | C | Φ120×133 | 79.17 × 59.44 |
