Large irradiation area,good uniformity Alternative shadowless light source
Large area of electronic components identification Mark point location Outline dimension measurement Robot picking
Download
| Product Model | Power(V/W) | Length(mm) | Width(mm) | The Poresize(mm) | |
| R | B/G/W | ||||
| LT-24V-60FK60 | 24V/4.32W | 24V/5.76W | 60 | 60 | 20*30 |
| LT-24V-100FK100 | 24V/10.80W | 24V/14.40W | 100 | 100 | 40*40 |
| LT-24V-150FK150 | 24V/15.12W | 24V/20.16W | 150 | 150 | 30*30 |
| LT-24V-170FK130 | 24V/23.40W | 24V/31.20W | 170 | 130 | 40*40 |
| LT-24V-170FK170 | 24V/38.16W | 24V/50.88W | 170 | 170 | 44*44 |
| LT-24V-172FK132 | 24V/36.72W | 24V/48W | 172 | 132 | 40*40 |
| LT-24V-190FK110 | 24V/26.64W | 24V/35.52W | 190 | 110 | 35*35 |
| LT-24V-200FK100 | 24V/13.68W | 24V/18.24W | 200 | 100 | 35*35 |
| LT-24V-224FK174 | 24V/46.08W | 24V/21.8W | 224 | 174 | 35*35 |
| LT-24V-232FK232 | 24V/20.16W | 24V/26.88W | 232 | 232 | 35*35 |
| LT-24V-270FK232 | 24V/24.48W | 24V/32.64W | 270 | 232 | 110*110 |
| LT-24V-300FK300 | 24V/67.68W | 24V/90.24W | 300 | 300 | 60*60 |
| LT-24V-360FK250 | 24V/66.24W | 24V/88.32W | 360 | 250 | 110*110 |
| LT-24V-462FK462 | 24V/115.20W | 24V/153.60W | 462 | 462 | 100*100 |
| LT-24V-575FK375 | 24V/246.24W | 24V/328.32W | 575 | 375 | 155*115 |
