Develop high-precision, high-speed and high-performance three-axis robots independently.
The detachable cable module connecting the control cabinet and the main body facilitates transportation and assembly.
Compact in structure, flexible and small in size, with a large range of motion.
It is applicable to scenarios such as screw fastening, soldering, and dispensing.
Download
| Product model | TM5-R345-3 | |||
| Installation method | Countertop installation | |||
| workspace | Joint1+Joint2 | 345mm | ||
| Joint1 | 250mm | |||
| Joint2 | 95mm | |||
| Body weight (excluding cables) | 11.3kg | |||
| Repeatability | Joint1+Joint2 | ±0.02mm | ||
| Joint3 | ±0.01mm | |||
| speed of movement | Joint1+Joint2 | 6500mm/s | ||
| Joint3 | 450mm/s | |||
| range of motion | Joint1 | ±140° | ||
| Joint2 | ±132° | |||
| Joint3 | 100mm | |||
| Load | Rated | 2Kg | ||
| maximum | 5Kg | |||
| ambient temperature | 5~40℃ | |||
| User circuit | 15-pin (D-Sub interface) | |||
| User gas line | Φ4mmx2，Φ6mmx2 | |||
