The thrust density is high, and the iron core adopts a laminated structure to concentrate the magnetic flux.
The core design is very economical and only requires a single row of magnets.
The laminated structure and large surface area ensure good heat dissipation.
Modular magnetic tracks allow for unlimited travel lengths.
Download
| BFMC06 Series Technical Data | ||||||
| Performance Parameters | Symbol | Unit | BFMC06030 | BFMC06050 | BFMC06075 | BFMC06100 |
| Peak Force | Fp | N | 379 | 632 | 948 | 1263 |
| Continuous Force | Fc | N | 125 | 210 | 315 | 420 |
| Motor Constant | Km | N/SQRT (W) | 16.1 | 22.5 | 29.7 | 36.6 |
| Peak Current | IP | Arms | 15 | 15 | 15 | 15 |
| Continuous Current | lc | Arms | 4 | 4 | 4 | 4 |
| Resistance@25°℃ | Rm | Ohms L-L | 2.5 | 3.6 | 4.7 | 5.5 |
| Inductance | L | mH L-L | 13.8 | 23 | 33 | 44 |
| Back EMF Constant | Ke | Vpeak/m/s L-L | 25.8 | 43.0 | 64.5 | 86.0 |
| Force Constant | Kf | N/Ams | 31.3 | 52.5 | 78.8 | 105 |
| Electrical Time Constant | Te | ms | 5.5 | 6.3 | 7.0 | 8.0 |
| Electrical Cycle(N to N) | 2T | mm | 30 | 30 | 30 | 30 |
| Max Coil Temperature | Tmax | °℃ | 130 | 130 | 130 | 130 |
| MagneticAttraction | Fa | kN | 0.6 | 0.9 | 1.4 | 1.9 |
| Coil Mass | Mc | kg | 1.15 | 1.75 | 2.25 | 2.95 |
| Track Mass | Mw | kg/m | 2.5 | 3.8 | 5 | 6.5 |
