Compact and lightweight, it is lighter in weight compared with traditional linear motors.
The zero cogging effect coreless design achieves zero cogging effect.
The nominal annular air gap with a large air gap of 0.5mm to 1.75mm facilitates installation and centering.
Closed magnetic bodies, suitable for various environments.
Download
| BSM16 Series Performance Parameters | ||||||
| Performance Parametes | Symbol | Uni | BSM1603 | BSM1606 | BSM1609 | BSM1612 |
| Peak Force | Fp | N | 24 | 48 | 72 | 96 |
| Continuous Force | Fc | N | 6 | 12 | 18 | 24 |
| Motor Constant | Km | N/SQRT (W) | 2.34 | 3.3 | 4 | 4.7 |
| Peak Current | Ip | Ams | 4.4 | 4.4 | 4.4 | 4.4 |
| Continuous Current | Ic | Arms | 1.1 | 1.1 | 1.1 | 1.1 |
| Resistance@25℃ | Rm | Ohms L-L | 3.6 | 7.2 | 11 | 14.4 |
| Inductance | L | mH L-L | 1.6 | 3.2 | 5 | 6.4 |
| Back EMF Constant | Ke | Vpeak/m/s L-L | 4.5 | 9 | 13.4 | 18 |
| Force Constant | Kf | N/Ams | 5.5 | 11 | 16.4 | 22 |
| Electrical Time Constant | Te | ms | 0.45 | 0.45 | 0.45 | 0.45 |
| Electrcal Cycle(N to N) | 2t | mm | 60 | 60 | 60 | 60 |
| Max Coil Temperature | Tmax | ℃ | 130 | 130 | 130 | 130 |
| Magnetic Attraction | Fa | kN | 0 | 0 | 0 | 0 |
| Coil Mass | Mc | kg | 0.08 | 0.16 | 0.2 | 0.32 |
