Extremely compact structure with built-in controller
Extremely short response time
Extremely wide zoom range
Large field of view,no vignetting
High resolution,low distortion
Download
| Model |
Focal Length |
F/# | Mag. | WD mm |
object Circle mm |
Detector Type |
TV Distortion % |
Relative illumination % |
mount | Dimensions mm×mm |
| PPL11-1648-12EC1 | 16mm | 4.8 | 0~0.2 | 50~∞ | 92~∞ | 1.1＂ | <0.01 | >88 | C | Ф55×97 |
| PPL11-2542-12EC1 | 25mm | 4.2 | 0~0.3 | 50~∞ | 61.3~∞ | 1.1＂ | <0.06 | >92 | C | Ф45×90.7 |
| PPL11-3542-12EC1 | 35mm | 4.2 | 0~0.25 | 100~∞ | 73.6~∞ | 1.1＂ | <0.05 | >93 | C | Ф48×93.1 |
| PPL11-5040-12EC1 | 50MM | 4.0 | 0~0.27 | 150~∞ | 68~∞ | 1.1＂ | <0.05 | >96 | C | Ф44×86.7 |
