A full closed-loop feedback system with magnetic grating ruler (standard configuration) or optical grating ruler, with a resolution as high as 0.1 μm.
The repeatability positioning accuracy is ±2μm, and higher-precision motion platforms can be customized and developed according to customer requirements.
Download
Module width
95mmload
15kgitinerary
90~1230mm
