The side view Angle can reach 45,and the side image occupies a large proportion Built-in light source,easy to fill light on the top or inside side of the object
Suitable for the detection of materials with diameters of 20~40mm
Download
| Model |
WD mm |
Effective F Number |
Wavelength Range (nm) |
Mount |
Dimensions mm×mm |
Illuminator Voltage V, DC |
Illuminator Power W |
Object Field of View Diameter x Depth （mm×mm） 1"13.13*8.76 or13.11*9.83 |
|
| TCSEP-1-20M-40 | 1~40 | 2.4~16 | 450~650 | C | Φ140×294 | 24 | 1.7 | Min 20×25 | Max 40×5 |
