变倍斜像镜头

产品参数

产品型号	放大倍率	工作距离mm	匹配的最大CCD尺寸	像方最佳MTF	物像距mm	像方最佳F/#	相机接口
TCSZSM-1-014-018	0.135~0.178	150~200	1"	55	223.8~272.6	15.4	C

放大倍率 X	工作距离mm	相机与镜头接倾斜 (°)	物体相对镜头倾斜 (°)	探测器长边沿倾斜方向时的物方视野
				1"	1"	2/3"
				14.13*7.45mm	13.13*8.76mm	8.45*7.07mm
				物方视野L×W(W)(mm×mm)
0.178	150	0	0	79.38×41.85(41.85)	73.76×49.21(49.21)	47.47×39.72(39.72)
		2.7	15	82.35×44.81(39.16)	76.49×52.44(46.26)	49.22×41.44(38.21)
		5.9	30	92.99×48.85(36.53)	86.18×56.78(43.34)	54.99×43.54(36.58)
		10.2	45	117.56×55.55(33.51)	108.30×63.85(39.97)	67.65×46.72(34.60)
0.167	160	0	0	84.61×44.61(44.61)	78.62×52.46(52.46)	50.60×42.34(42.34)
		2.6	15	87.58×47.65(41.64)	81.35×55.76(49.19)	52.36×44.07(40.64)
		5.6	30	98.94×51.95(38.84)	91.70×60.38(46.09)	58.53×46.31(38.91)
		9.6	45	125.26×59.10(35.62)	115.39×67.93(42.49)	72.09×49.70(36.80)
0.158	170	0	0	89.43×47.15(47.15)	83.10 ×55.44(55.44)	53.48×44.75(44.75)
		2.4	15	92.80×50.49(44.12)	86.20×59.08(52.13)	55.50×46.71(43.07)
		5.8	30	104.89×55.04(41.15)	97.21×63.98(48.83)	62.06×49.09(41.23)
		9	45	132.94×62.64(37.73)	122.47×72.00(45.01)	76.52×52.69(38.99)
0.149	180	0	0	94.83×50.00(50.00)	88.12×58.79(58.79)	56.71×47.45(47.45)
		2.3	15	98.03×53.32(46.60)	91.06×62.40(55.06)	58.64×49.35(45.51)
		5	30	110.84×58.14(43.46)	102.72×67.58(51.57)	65.60×51.86(43.56)
		8.6	45	140.6×66.18(39.84)	129.54×76.07(47.53)	80.95×55.68(41.19)
0.142	190	0	0	99.51×52.46(52.46)	92.46×61.69(61.69)	59.51×49.79(49.79)
		2.2	15	103.25×56.16(49.08)	95.91×65.72(57.99)	61.77×51.98(47.94)
		4.7	30	116.78×61.23(45.77)	108.23×71.17(54.32)	69.13×54.63(45.88)
		8.1	45	148.27×69.72(41.96)	136.59×80.14(50.05)	85.37×58.66(43.38)
0.135	200	0	0	104.67×55.19(55.19)	97.26×64.89(64.89)	62.59×52.37(52.37)
		2.1	15	108.47×59.00(51.56)	100.76×69.04(60.92)	64.91×54.62(50.37)
		4.5	30	122.71×64.33(48.08)	113.73×74.77(57.06)	72.66×57.41(48.21)
		7.7	45	155.92×73.26(44.07)	143.64×84.21(52.57)	89.79×61.65(45.58)

产品型号	放大倍率	工作距离 mm	匹配的最大CCD尺寸	像方最佳MTF	物像距mm	像方最佳F/#	相机接口
TCSZSM-23-0110	0.1~1.0	40.9~261.6	2/3"	60~110	109.1-329.8	8.8~16.0	C

放大倍率 X	工作距离mm	相机与镜头接倾斜 (°)	物体相对镜头倾斜 (°)	探测器长边沿倾斜方向时的物方视野
				2/3"	1/1.8"	1/2"
				8.45*7.07mm	7.16*5.44mm	6.40*4.80mm
				物方视野L×W(W)(mm×mm)
1	40.9	0	0	8.45×7.07(7.07)	7.16×5.44(5.44)	6.40 ×4.80(4.80)
		5	5	8.46×7.18(6.98)	7.17×5.51(5.38)	6.40 ×4.85(4.75)
		10	10	8.47×7.27(6.89)	7.17×5.57(5.32)	6.41×4.90(4.71)
		15	15	8.47×7.37(6.81)	7.17×5.64(5.27)	6.41×4.95(4.66)
0.75	43.1	0	0	11.27×9.43(9.43)	9.55×7.25(7.25)	8.53×6.40(6.40)
		5.6	7.5	11.33×9.63(9.25)	9.59×7.39(7.14)	8.57×6.50(6.31)
		11.4	15	11.47×9.84(9.07)	9.71×7.52(7.02)	8.68×6.61(6.21)
		15.3	20	11.62×9.98(8.95)	9.83×7.61(6.94)	8.78×6.68(6.15)
0.5	54.6	0	0	16.90×14.14(14.14)	14.32×10.88(10.88)	12.80×9.60(9.60)
		5	10	17.13×14.55(13.79)	14.51×11.15(10.65)	12.96×9.81(9.41)
		10.3	20	17.77×14.99(13.42)	15.04×11.42(10.40)	13.43×10.03(9.22)
		16.1	30	18.91×15.48(13.04)	15.99×11.74(10.15)	14.27×10.27(9.02)
0.33	78.1	0	0	25.63×21.44(21.44)	21.71×16.50(16.50)	19.40×14.55(14.55)
		3.3	10	26.00×22.04(20.88)	22.02×16.88(16.12)	19.68×14.86(14.26)
		6.8	20	27.17×22.71(20.31)	22.99×17.31(15.75)	20.54×15.19(13.96)
		10.8	30	29.30×23.50(19.72)	24.76×17.82(15.36)	22.11×15.59(13.65)
0.2	128.4	0	0	42.25×35.35(35.35)	35.80×27.20(27.20)	32.00×24.00(24.00)
		3.1	15	43.75×36.87(33.95)	37.05×28.18(26.28)	33.11×24.77(23.27)
		6.6	30	48.84×38.78(32.48)	41.29×29.40(25.30)	36.86×25.72(22.49)
		11.3	45	59.96×41.65(30.70)	50.47×31.19(24.11)	44.96×27.10(21.53)
0.1	261.6	0	0	84.50×70.70(70.70)	71.60×54.40(54.40)	64.00×48.00(48.00)
		1.5	15	87.25×73.45(67.63)	73.90×56.16(52.36)	66.05×49.36(46.37)
		3.3	30	97.79×77.29(64.67)	82.69×58.60(50.40)	73.83×51.27(44.80)
		5.7	45	121.28×83.18(61.05)	102.09×62.29(47.96)	90.95×54.11(42.84)

外形尺寸图

TCSZSM-1-014-018

TCSZSM-23-0110

产品特点
